Nanofix Hotmelt Glue 5510 1PCS 25 Kg

PRODUCT FEATURES AND APPLICATION

INFUSE 540 is an E.V.A based (ethylene vinyl acetate copolymer) adhesive with medium-low viscosity and good heat resistance. Its high adhesive strength provides good results, especially when bonding PVC edgebanding. INFUSE 540 is used for bonding PVC, ABS, Polyester, Melamine, Laminate and Polyester edgebandings on automatic machines.

INSTRUCTIONS FOR USE

Temperature in Tank 170-200 °C
Temperature on the Roll 180-200 °C
Material and Environmental Temperature: > 15 °C
Moisture in Material: 0.8-10 %
Application Speed: 18-50 Meters /Minute
Application Pressure: 3-5 Kg/cm2

TECHNICAL SPECIFICATIONS

Adhesive type: Synthetic resin based
Color options: Natural, White, Brown, Black
Physical form Solid granules.
Melting index: 80-100 g/10min @200°C (ASTM D1238/ISO 1133)
Viscosity : 75.000 +/- 5.000 mPa.s @200°C
Brookfield Thermosel: 110,000 +/- 5,000 mPa.s @180°C
Spindle 27/10 rmp (ASTM D562): 165,000 +/- 5,000 mPa.s @170°C
Density: 1.33 +/- 0.05 g/cm3 (ASTM D1505/ISO 1183)
Softening Point: 100 +/- 3 °C Degree (according to ASTM D36/DIN 52 011 Ring and Ball method)
Compound strength 10 MPa (ASTM D638/ISO 527)

Product Features

Universal use (compatibility with many machines)

High ultimate adhesion strength

Good flow properties

Very good soaking
